Thông số kỹ thuật:
Approvals / Compliance
The system supports either single link or single head DVI resolutions to a maximum of 1920 x 1200@ 60Hz
The system delivers analogue stereo audio (Line in, Line Out) via digital signalling between any transmitter/receiver pair.
Audio output of any transmitter can be multicast to many receivers.
Supports USB2.0 devices (Low, Full and High speed). The system has a security feature, which allows the blocking of non-HID devices. Isochronous devices are not supported (i.e. USB audio or video devices).
CATx (up to 100m/330ft) or fiber (requirements dependent)
0 to 40ºC / 32 to 104ºF
Connectors – Local Unit
1 x DVI-D, audio 3.5mm in, audio 3.5mm out, USB type B, RS232 9-pin D-type. 1 x 8p8c and 1 x SFP for ADDERLink Infinity network connections.
Connectors – Remote Unit
1 x DVI-D, audio 3.5mm in, audio 3.5mm out, 4 x USB type A, RS232 9-pin D-type. 1 x 8p8c and 1 x SFP for ADDERLink Infinity network connections.
1U compact case, robust metal construction. 198mm/7.92” (w), 44mm/1.76” (h), 150mm/6.0” (d), 1.1kg/2.7lbs.
2.5mm DC jack (power adapter included),100-240VAC 50/60Hz, 0.8A, input to power adapter. 5VDC 20W output from power adapter.
All known operating systems.
